P8mm outdoor lED display screen For Shopping Center Advertising
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | CRTOP |
| Certification: | CE/FCC/ETL |
| Model Number: | P8mm |
|
Detail Information |
|||
| Pixel Pitch: | 8mm | Module Resolution: | 40(W)*20(H) |
|---|---|---|---|
| Module Size: | 320mm*160mm | Refresh Rate: | Normal Refresh |
| Protection Class: | Front IP65, Back IP43 | White Balance Brightness: | ≥ 5500cd/㎡ |
| Grayscale: | 16Bit | Contrast: | ≥3000:1 |
| Color Temperature: | 3200K—9300K Adjustable | ||
| High Light: | P8mm Outdoor LED Display Screen,5500cd Outdoor LED Display Screen,5500cd P8 Led Display |
||
Product Description
P8mm Outdoor LED Display Screen For Shopping Center Advertising
P8 watertight Outdoor Led advertising Screen for shopping center
1. Using high-grade chip packaged LED lights, low gray and high brightness, fully guarantees the service life and display quality of the display screen.
2.The display system meets the requirements of water-proof, moisture-proof, corrosion-proof, wind-proof, high temperature-proof, anti-static, fire-proof, flame-proof and earthquake-proof.
3.The image color is soft and lifelike, the gray scale is rich, the level sense and the three-dimensional sense are strong.
Pitch:P2.5, P3, P3.07, P3.91, P4, P5, P5.33, P6.66, P8, P10
Module size:192x192mm,160x160mm,320x160mm,250x250mm,256x128mm
Cabinet size:640x640mm,768x768mm,960*960mm,500x500mm,1024x768mm 1024x768mm
| project | parameter | Remark | |
BASIC PARAMETER | pixel pitch | 8mm | |
| pixel structure | 1R1G1B | ||
| pixel density | 15625/m 2 | ||
| Module resolution | 40(W)*20(H) | ||
| Module size | 320mm*160mm | ||
| Box size | 960mm*960mm | ||
OPTIC PARAMETER | Single point luminance, chromaticity correction | have | |
| white balance brightness | ≥ 55 00cd/㎡ | ||
| color temperature | 3200K—9300K adjustable | ||
| Horizontal viewing angle | ≥ 120° | ||
| vertical viewing angle | ≥ 120° | ||
| Visible distance | ≥16 meters | ||
| Brightness uniformity | ≥97% | ||
| Contrast | ≥3000:1 | ||
Proccessing Performance | Signal processing bits | 16 bits*3 | |
| grayscale | 16Bit | ||
| control distance | Gigabit Ethernet cable: 100 meters, Optical fiber: 10 kilometers | ||
| drive mode | High gray-scale constant current source driver IC | ||
| frame rate | ≥ 60HZ | ||
| refresh rate | ≥ 1920 Hz | ||
| way to control | Synchronize | ||
| Brightness adjustment range | 0 to 100 stepless adjustment | ||
Operation performance | Continuous working time | ≥72 hours | |
| Typical life | 50,000 hours | ||
| Protection class | Front IP65, back IP43 | ||
| range of working temperature | -20℃ to 50℃ | ||
| Operating humidity range | 10 %- 80% RH non-condensing | ||
| Storage temperature range | -20 ℃ to 60 ℃ | ||
Electric parameter | Operating Voltage | DC 5V | |
| Power Requirements | AC: 220×(1±10%)V, 50×(1±5%)Hz | ||
| Maximum power consumption | 850W/ ㎡ | ||
| Average power consumption | 360W/ ㎡ | ||
