Automatic Brightness P8 LED Video Screen Rental For Shopping Center
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | CRTOP |
| Certification: | CE/FCC/ETL |
| Model Number: | P8mm |
|
Detail Information |
|||
| Pixel Pitch: | 8mm | Module Resolution: | 32(W)*16(H) |
|---|---|---|---|
| Module Size: | 256mm*128mm | Refresh Rate: | High Refresh |
| Protection Class: | Front IP65, Back IP43 | White Balance Brightness: | ≥ 5500cd/㎡ |
| Grayscale: | 16Bit | Contrast: | ≥3000:1 |
| Horizontal Viewing Angle: | ≥ 120° | Vertical Viewing Angle: | ≥ 120° |
| High Light: | P8 LED Video Screen Rental,IP65 LED Video Wall Rental,IP65 LED Video Screen Rental |
||
Product Description
Automatic Brightness P8 LED Video Screen Rental For Shopping Center
P8 Automatic brightness adjustment Outdoor Led Screen for shopping center
1. Using high-grade chip packaged LED lights, low gray and high brightness, fully guarantees the service life and display quality of the display screen.
2.The advantage of this driver chip is that it can reduce the voltage falling on the output terminals of the IC. Reduce the power consumption, improve the power loss of the IC, and then achieve the effect of energy saving.
3.High refresh rate, the video picture is more delicate and smooth; High contrast ratio, improve the contrast between light and dark, enhance the picture details, restore the true color
Pitch:P2.5, P3, P3.07, P3.91, P4, P5, P5.33, P6.66, P8, P10
Module size:192x192mm,160x160mm,320x160mm,250x250mm,256x128mm
Cabinet size:640x640mm,768x768mm,960*960mm,500x500mm,1024x768mm 1024x768mm
| project | parameter | Remark | |
BASIC PARAMETER | pixel pitch | 8mm | |
| pixel structure | 1R1G1B | ||
| pixel density | 15625/m 2 | ||
| Module resolution | 32(W)*16(H) | ||
| Module size | 256mm*128mm | ||
| Box size | 1024mm*768mm | ||
OPTIC PARAMETER | Single point luminance, chromaticity correction | have | |
| white balance brightness | ≥ 55 00cd/㎡ | ||
| color temperature | 3200K—9300K adjustable | ||
| Horizontal viewing angle | ≥ 120° | ||
| vertical viewing angle | ≥ 120° | ||
| Visible distance | ≥16 meters | ||
| Brightness uniformity | ≥97% | ||
| Contrast | ≥3000:1 | ||
Proccessing Performance | Signal processing bits | 16 bits*3 | |
| grayscale | 16Bit | ||
| control distance | Gigabit Ethernet cable: 100 meters, Optical fiber: 10 kilometers | ||
| drive mode | High gray-scale constant current source driver IC | ||
| frame rate | ≥ 60HZ | ||
| refresh rate | ≥ 3840 Hz | ||
| way to control | Synchronize | ||
| Brightness adjustment range | 0 to 100 stepless adjustment | ||
Operation performance | Continuous working time | ≥72 hours | |
| Typical life | 50,000 hours | ||
| Protection class | Front IP65, back IP43 | ||
| range of working temperature | -20℃ to 50℃ | ||
| Operating humidity range | 10 %- 80% RH non-condensing | ||
| Storage temperature range | -20 ℃ to 60 ℃ | ||
Electric parameter | Operating Voltage | DC 5V | |
| Power Requirements | AC: 220×(1±10%)V, 50×(1±5%)Hz | ||
| Maximum power consumption | 850W/ ㎡ | ||
| Average power consumption | 360W/ ㎡ | ||
