Transparent Asynchronous Car LED Advertising Screen For Back Window
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | CRTOP |
| Certification: | CE/FCC/ETL |
| Model Number: | P2.6 -P5.2mm |
|
Detail Information |
|||
| Product Number: | P2.6 -P5.2mm | Glowing Point Color: | 1R1G1B |
|---|---|---|---|
| Module Size: | W 156mm * H 249.6mm | Pixel Density: | 73964 Pixels/m² |
| Physical Point Spacing: | W5.2mm*H P2.6mm | Average Power Consumption: | < 45W |
| Maximum Power Consumption: | < 100W | Way To Control: | Default Asynchronous Control |
| High Light: | 45W Car LED Advertising Screen,100W Car LED Advertising Screen,45W Car Back Window Led Display |
||
Product Description
Transparent Asynchronous Car LED Advertising Screen For Back Window
Unique design P2.6 -P5.2mm transparent Car Led screen
1. Application of car transparent screen.Car transparent screen series is a series of transparent display screens specially tailored by our company for the rear window glass of small cars . With the continuous improvement of transparent screen technology , the application of vehicle- mounted transparent screen is rapidly popularized and in the ascendant .
2. The screen is designed with light bar grid, with good light transmission.Between the LED transparent screen light strips is a physical hollowed-out light-transmitting area, with a light transmittance of about 50%, so it will not completely block the lighting and will not affect the driver's safe driving.In addition , P 5.2- P2. 6 All the wires are gathered insulation protection , and the back of the screen is made of a full-face acrylic board , which is a two-way protection for the screen and passengers . Passengers can not directly touch the screen body , eliminating the need for Except for the safety hazard .
perspective 140°(W) 140°(H)
ambient temperature -20℃～+ 70 ℃
Relative humidity 10%-75% non-condensing
Protection class IP3 0 ( This product is strictly waterproof , can not get wet , can not be washed )
|
module
|
project | parameter |
| Product number | P2.6 -P5.2 | |
| Module size | W 156mm * H 249.6mm | |
| Physical point spacing | W5.2mm*H P2.6mm | |
| pixel density | 73 964 pixels/m² | |
| Glowing point color | 1R1G1B | |
| LED package | SMD1921 | |
| Module Resolution | 30 (W)* 96 (H) | |
| drive mode | Constant current drive | |
| white balance brightness | 2500cd/m 2 | |
| refresh rate | ≥1920-3840Hz | |
|
LED Box |
Dimensions of the outer edge of the box | W 786.4 mm*H 256 mm |
|
Display area size
|
W 780mm * H 249.6mm | |
| Number of single modules | 5pcs _ | |
| Power supply | Vehicle power supply | |
| Cabinet resolution | W1 5 0*H 96 dots | |
| box material quality | Acrylic whole board | |
| Closest viewing distance | 4m |
|
LED box |
perspective | 140°(W) 140°(H) |
| ambient temperature | -20℃～+ 70 ℃ | |
| Relative humidity | 10%-75% non-condensing | |
| Protection class | IP3 0 ( This product is strictly waterproof , can not get wet , can not be washed ) | |
| Overall thickness | 55 mm (including power supply) | |
| match system card | Carlette / Xixun | |
|
The main technical parameters |
Operating Voltage | AC 12V (vehicle light modification) |
| Average power consumption | < 45W _ | |
| Maximum power consumption | < 100W _ | |
|
way to control
|
Default asynchronous control | |
|
Grayscale/Color |
Class 16384 | |
| MTBF | >9000hours |
