Source manufacturer 512x512 aluminum die cast cabinet P2mm indoor led display led screen
Product Details:
| Place of Origin: | CHIAN |
| Brand Name: | CRTOP |
| Certification: | CE/FCC |
| Model Number: | P2mm |
|
Detail Information |
|||
| Pitch:: | 2mm | Cabinet Size:480: | 512x512mm |
|---|---|---|---|
| Box: | Aluminum Die Cast | Led Lamp: | Hongsheng |
| Refresh: | Normal Refresh | View Angele: | 140º |
| View Distance: | 5m | Brightness: | ≧600-2000cd |
| Contrast Ratio:: | 3000:1 | Brightness Uniformity: | ≧97% |
| Characteristic: | No Fan And Mute | ||
Product Description
Source manufacturer 512x512 aluminum die cast cabinet P2mm indoor led display led screen
indoor Led Display, Led Screen, Led vedio panel
Product features:
1, die cast aluminum box flatness is high, pure before maintenance or normal cabinet
2, high refresh rate, high gray scale
3, high contrast
4. No fan and mute
5, seamless stitching, fast installation
6. LED lights: SMD full-color series, using high-end chip packaged LED lights from world-renowned manufacturers, providing customers with a variety of choices. At the same time, the service life and display quality of the display screen are fully guaranteed.
7. Driver IC: Adopt high refresh rate, high grayscale constant current driver IC from world-renowned top manufacturers, with excellent driving performance, stability and reliability.
parameter:
Cabiet size choice:
600x337.5mm
640x480mm
480x480mm
786*786mm
576*576mm
960*960mm
Custom Simple Box
Customize
Pitch:
P1.5625 p1.86 p1.875 p1.923 p2.5 p2.5 p2.22 p2 p3 P3.07 p4 p5 p6
Module size:128*96mm,160*160mm,320*160mm,200*200mm,240*240mm,192*192mm,
256*128mm
white balance brightness:≥600 cd-1500cd /㎡
Horizontal viewing angle:≥ 140°
vertical viewing angle: ≥ 120°
Contrast ratio: ≥3000:1
refresh rate: ≥ 384 0 Hz
Protection class:IP20
Single point luminance, chromaticity correction :have
color temperature :3200K—9300K adjustable
Visible distance : ≥3 meters
Brightness uniformity : ≥97%
Signal processing bits :16 bits*3
Grayscale : 65536
control distance Network cable: 100 meters, Optical fiber: 10 kilometers
drive mode :High gray-scale constant current source driver IC
frame rate :≥ 60HZ
way to control :Synchronize
Brightness adjustment range:0 to 100 stepless adjustment
Continuous working time:≥72 hours
Typical life:100,000 hours
Protection class : IP20
Operating Voltage: DC: 4.2-5V
Power Requirements AC: 220×(1±10%)V, 50×(1±5%)Hz
Maximum power consumption :680W / ㎡
Average power consumption: 270W / ㎡
