P2.22mm Indoor LED Display Screen Vedio Wall Aluminum Die Cast Box

P2.22mm Indoor LED Display Screen Vedio Wall Aluminum Die Cast Box

Product Details:

Place of Origin: CHIAN
Brand Name: CRTOP
Certification: CE/FCC
Model Number: P2.22mm
Get Best Price Contact Now

Detail Information

Pitch:: 2.22mm Cabinet Size: 480x480mm
Box: Aluminum Die Cast IC: SM16380
View Angele: 140º View Distance: 5m
Brightness: ≧600-2000cd Contrast Ratio:: 3000:1
Full Color: SMD Full-color Characteristic: High Grayscale Constant Current Driver IC
High Light:

P2.22mm Indoor LED Display Screen

,

480x480mm Indoor LED Display Screen

,

P2.22mm Indoor Advertising Display

Product Description

P2.22mm Indoor LED Display Screen Vedio Wall Aluminum Die Cast Box



P2.22mm aluminum die cast box indoor led display led screen led vedio wall

indoor Led Display, Led Screen, Led vedio panel

Product features:

1, die cast aluminum box flatness is high, pure before maintenance or normal cabinet

2, high refresh rate, high gray scale

3, high contrast

4. No fan and mute

5, seamless stitching, fast installation

6.The multi-layer circuit design ensures uniform current distribution of the lamp board, good heat dissipation, prevents color blocks at low gray, and enhances the anti-electromagnetic interference ability. High-quality manufacturers in the sheet metal industry: Shengyi, Kingboard (KB), etc.

7. Driver IC: Adopt high refresh rate, high grayscale constant current driver IC from world-renowned top manufacturers, with excellent driving performance, stability and reliability.

8. Connector: High-quality 3U gold-plated connector is used, and there is no cable connection in the box, which is stable and reliable.



parameter:

Cabiet size choice:

600x337.5mm

640x480mm

480x480mm

786*786mm

576*576mm

960*960mm

Custom Simple Box

Customize

Pitch:

P1.5625 p1.86 p1.875 p1.923 p2.5 p2.5 p2.22 p2 p3 P3.07 p4 p5 p6

Module size:128*96mm,160*160mm,320*160mm,200*200mm,240*240mm,192*192mm,

256*128mm



white balance brightness:≥600 cd-2000cd /㎡

Horizontal viewing angle:≥ 140°

vertical viewing angle: ≥ 120°

Contrast ratio: ≥3000:1

refresh rate: ≥ 384 0 Hz

Protection class:IP20

Single point luminance, chromaticity correction :have

color temperature :3200K—9300K adjustable

Visible distance : ≥3 meters

Brightness uniformity : ≥97%

Signal processing bits :16 bits*3

Grayscale : 65536

control distance Network cable: 100 meters, Optical fiber: 10 kilometers

drive mode :High gray-scale constant current source driver IC

frame rate :≥ 60HZ

way to control :Synchronize

Brightness adjustment range:0 to 100 stepless adjustment

Continuous working time:≥72 hours

Typical life:100,000 hours

Protection class : IP20

Operating Voltage: DC: 4.2-5V

Power Requirements AC: 220×(1±10%)V, 50×(1±5%)Hz

Maximum power consumption :680W / ㎡

Average power consumption: 270W / ㎡
