Energy Saving P4mm Large Outdoor Display Screen Full Color Display
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | CRTOP |
| Certification: | CE/FCC |
| Model Number: | P4mm |
|
Detail Information |
|||
| Pixel Pitch: | 4mm | Refresh Rate: | High Refresh |
|---|---|---|---|
| Light: | Normal1921 | Pixel Structure: | 1R1G1B |
| Module Resolution: | 64 (W)* 32 (H) | Module Size: | 256mm * 1 28mm |
| Color Temperature: | 3200K—9300K Adjustable | Visible Distance: | ≥32 Meters |
| High Light: | P4mm Large Outdoor Display Screen,1R1G1B LED Full Color Display,1R1G1B Large Outdoor Display Screen |
||
Product Description
Energy Saving P4mm Large Outdoor Display Screen Full Color Display
Energy saving P4mm Outdoor advertising display
1. Standard 1920Hz refresh rate, the video picture is more delicate and smooth; 9000:1 high contrast ratio, improve the contrast between light and dark, enhance the picture details, restore the true color
2. Diversely used in commercial real estate, shopping malls, large squares, outdoor advertising screens, traffic screens and other fields
3. Good waterproof performance, strong anti-ultraviolet, IP65 or above protection level, can deal with all kinds of bad weather. Green and environmental protection, the main light-emitting device of outdoor LED display is LED lamp beads, which are made of non-toxic materials, unlike fluorescent lamps that contain mercury, which will cause pollution, and LEDs can also be recycled.
The outdoor LED display has high brightness, the general brightness is 5500cd, and the brightest can reach more than 10000cd. Even under strong light, it can be clearly seen and the display effect is good.
4. Support 4.2V~5V and 2.8V/3.8V power supply mode, the power supply selection is more flexible, and there is no risk of burning the module with mixed power supply
5. a variety of module sizes , flexible collocation, more considerate upgrades , strict material selection
pixel pitch: 4 mm
pixel structure :1R1G1B
Module size :256mm * 1 28mm
color temperature: 3200K—9300K adjustable
drive mode: High gray-scale constant current source driver IC
Protection class: Front IP65, back IP43
Storage temperature range: -20 ℃ to 60 ℃
Pitch:P2.5, P3, P3.07, P3.91, P4, P5, P5.33, P6.66, P8, P10
Module size:192x192mm,160x160mm,320x160mm,250x250mm,256x128mm
Cabinet size:640x640mm,768x768mm,960*960mm,500x500mm,1024x768mm 1024x768mm,
| project | Parameter | Remark | |
|
Basic parameters |
pixel pitch | 4 mm | |
| pixel structure | 1R1G1B | ||
| pixel density | 62500/m 2 | ||
| Module resolution | 64 (W)* 32 (H) | ||
| Module size | 256mm * 1 28mm | ||
| Box size | 1024*768mm | ||
|
Optical parameters |
Single point luminance, chromaticity correction | have | |
| white balance brightness | ≥6000cd/㎡ | ||
| color temperature | 3200K—9300K adjustable | ||
| Horizontal viewing angle | ≥120° | ||
| vertical viewing angle | ≥120° | ||
| Visible distance | ≥32 meters | ||
| Brightness uniformity | ≥97% | ||
| Contrast | ≥3000:1 | ||
|
Processing performance |
Signal processing bits | 16 bits*3 | |
| grayscale | 16Bit | ||
| control distance | Gigabit Ethernet cable: 100 meters, Fiber: 10 kilometers | ||
| drive mode | High gray-scale constant current source driver IC | ||
| frame rate | ≥60HZ | ||
| refresh rate | ≥3840HZ | ||
| way to control | Synchronize | ||
| Brightness adjustment range | 0 to 100 infinitely adjustable | ||
|
Use parameters |
Continuous working time | ≥72 hours | |
| Typical life | 50,000 hours | ||
| Protection class | Front IP65, back IP43 | ||
| range of working temperature | -20℃ to 50℃ | ||
| Operating humidity range | 10 %- 80% RH non-condensing | ||
| Storage temperature range | -20 ℃ to 60 ℃ | ||
| Electrical parameters | Operating Voltage | DC 5V | |
| Power Requirements |
AC: 220×(1±10%) V, 50×(1±5%) Hz |
||
| Maximum power consumption | 600W/㎡ | ||
| Average power consumption | 230W/㎡ | ||
